SOFT drive mechanical steel trip edge “Heavy duty” multi-section ¾’’ x 6’’ x 24″ (HD)
Mobile steel trip edge following the imperfection of roads, exclusive Metal Pless system, reduces up to 50% the use of salt and abrasives (LE)
Carbide cutting edge on main mouldboard only (LE)
SOFT drive mechanical steel trip edge on the wings
Heavy duty hydraulic cylinders for maximum strength
Self-leveling skid shoes on the wings made of CHT400 steel
180° multiple hydraulic side wing positions
Side wings made of “Heavy duty” steel CHT400
3 adjustable crossover relief valves for hydraulic protection on the side wings and power angle system
Lateral floating of the blade
Skid shoes (CHT400 steel) mounted on the back of the cutting edge (HD)
Female quick attach (to be specified)
Curb runners
Valve and Joystick 3 functions
Baked powder paint
This system requires 1 set of oil outlets
AVAILABLE OPTIONS – Maxxpro
Eight (8) button joystick and electric valve (operate all 8 functions by the press of a button) (electric over hydraulic 3 spools mounted on the blade with electric control and necessary cable for the installation in the tractor cab)
Power angle max. 102’’ only available on 10′ models
